Chicago Pneumatic 3 HP Rotary Screw Air Compressor, 9.8 CFM @ 150 PSI, 60 Gallon Tank & Air Dryer 230-Volt, 1-Phase | QRS 3.0 HPD-1 TM | 4152054797

Model:
QRS 3.0 HPD-1 TM
Vendor Item Number:
4152054797
+ -
$7,573.60
Call Any of our Sales Experts to Place an Order. We offer Expert Advice, Quick Quotes and Product Availability.
Our Team Consists of "Air Compressor Experts", Challenge Us!
Mon-Fri 8 am to 5:00 pm EST
Coming Soon; Hours to 8:00 pm EST

Call Toll Free: 866.778.6572 within the Lower 48 States

Outside the US: 508.230.7118

"Over 100 Years of Experience"
Ships Factory Direct

Rating:
100% of 100
  • DESCRIPTION
  • TECH DATA
  • PRODUCT REVIEWS
  • VIDEOS
  • Product Q & A

DESCRIPTION

Chicago Pneumatic 3 HP Rotary Screw Air Compressor, 9.8 CFM @ 150 PSI, 60 Gallon Tank & Air Dryer 230-Volt, 1-Phase | QRS 3.0 HPD-1 TM | 4152054797





Quiet Rotary Screw (QRS)



Engineered for high performance, efficiency and reliability, the Chicago Pneumatic line of QRS (Quiet Rotary Screw) air compressors can meet the compressed air demands of a tire shop, vehicle body, paint shops and automotive dealerships.

Quiet by design, the QRS can be installed almost anywhere. With standard mounted receiver tank and a 5 Year Warranty, the QRS is the leading rotary screw compressor for light industrial applications.

Features:

  • Low sound enclosure with compact dimensions
  • 150 psig standard
  • Continuous operating capability
  • Basemount (option)
  • Manual tank drain
  • Three (3) phase, 208/230/460 or 230/1/60
  • Start/Stop operation
  • Load/No Load operation with timed shutdown
  • UL and cUL approved control panel
  • 5 year warranty with authorized start-up

TECH DATA

  • Product Specification

    • Capacity (CFM) @ 150 PSI
      9.8 CFM @ 150 PSI
    • Compressor Style
      Lubricated Rotary Screw
    • Controls
      Start/Stop Operation (230/1/60 has timed shutdown)
    • Cooling Type
      Air Cooled
    • Dew Point
      39 F
    • Horsepower (HP)
      3
    • Min Ambient Temperature
      34° F
    • Oil Capacity
      0.66 Gallon
    • Oil Carryover
      3 ppm
    • Rated Duty Cycle
      100%
    • Tank Material
      Carbon Steel
  • Overview & Technical Details

    • Air Dryer Style
      Refrigerated
    • Certifications
      ASME Coded Tank
    • Electrical Starting
      Across the line Starting
    • Fluid Type
      Synthetic
    • Max Ambient Temperature
      104°F
    • Oil Type
      Synthetic
    • Power Source/Type
      Electric
    • Sound Level dBA
      61 dB(A)
  • Additional Features

    • Air Dryer Included
      Included
    • Tank Drain Valve
      Manual Drain
  • Connection

    • Connection NPT
      1/2"
  • Dimensions & Weight

    • Dimensions (L)(W)(H)
      56" x 24" x 50"
    • Height (inch)
      50"
    • Length (inch)
      56"
    • Width (inch)
      24"
    • Weight (lbs)
      565.000000
  • Motor Data

    • Motor Type
      TEFC
  • Power Requirements

    • 208/230/1/60
      18.7 Full Load Running Amps
    • Standard Voltages
      230/1/60
  • Tank Size

    • Air Tank Configuration
      Horizontal
    • Air Tank Included
      Included
    • Air Tank Size
      60 Gallon
    • Coded
      ASME Coded
    • Tank Size
      60 Gallon
  • Warranty

    • Optional Warranty
      5 Year Extended Warranty Optional
    • Standard Warranty
      1 Year Parts & Labor
